IRLML2244TRPBF Infineon Technologies IRLML2244TRPBF Real Image1 IRLML2244TRPBF Real Image2 IRLML2244TRPBF real image
Same model may have multiple batches, images only for reference.
IRLML2244TRPBF Infineon Technologies IRLML2244TRPBF Real Image1 IRLML2244TRPBF Real Image2 IRLML2244TRPBF real image
IRLML2244TRPBF Infineon Technologies IRLML2244TRPBF Real Image1 IRLML2244TRPBF Real Image2 IRLML2244TRPBF real image
Same model may have multiple batches, images only for reference.

IRLML2244TRPBF

Part No IRLML2244TRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 20V 4.3A SOT23
Datasheet
IRLML2244TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 4.3A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 2.5V, 4.5V
Gate-Source Threshold Voltage 1.1V @ 10μA
Max Gate Charge 6.9nC @ 4.5V
Max Input Capacitance 570pF @ 16V
Maximum Gate-Source Voltage ±12V
Power Dissipation (Max) 1.3W (Ta)
Maximum Rds On at Id,Vgs 54 mOhm @ 4.3A, 4.5V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package Micro3/SOT-23
Dimension TO-236-3, SC-59, SOT-23-3
Win Source Part Number 069724-IRLML2244TRPBF
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IRLML2244TRPBF CAD Model

Description

The Infineon Technologies 069724-IRLML2244TRPBF is a P-channel MOSFET discrete semiconductor product.

  • Drain-Source Breakdown Voltage: 20V
  • Continuous Drain Current: 4.3A (Ta) @ 25°C
  • Maximum Rds On: 54 mOhm @ 4.3A, 4.5V
  • Maximum Gate-Source Voltage: ±12V
  • Package: Micro3/SOT-23
  • Supply Voltage: 2.5V to 4.5V
  • Power Dissipation: 1.3W (Ta)
  • Temperature Range: -55°C to 150°C (TJ)
  • Supply and Demand Status: Limited
