IRLML2803TRPBF Infineon Technologies IRLML2803TRPBF Real Image
Same model may have multiple batches, images only for reference.
IRLML2803TRPBF Infineon Technologies IRLML2803TRPBF Real Image
IRLML2803TRPBF Infineon Technologies IRLML2803TRPBF Real Image
Same model may have multiple batches, images only for reference.

IRLML2803TRPBF

Part No IRLML2803TRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 30V 1.2A SOT-23
Datasheet
IRLML2803TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 1.2A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 1V @ 250μA
Max Gate Charge 5nC @ 10V
Max Input Capacitance 85pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 540mW (Ta)
Maximum Rds On at Id,Vgs 250 mOhm @ 910mA, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package Micro3/SOT-23
Dimension TO-236-3, SC-59, SOT-23-3
Win Source Part Number 017768-IRLML2803TRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Industrial
Ultra Librarian 3D Model Ultra Librarian IRLML2803TRPBF CAD Model

Description

The Infineon Technologies 017768-IRLML2803TRPBF is a N-channel MOSFET transistor designed for use in low power applications.

  • Drain-Source Breakdown Voltage: 30V
  • Continuous Drain Current: 1.2A @ 25°C
  • Package: Micro3/SOT-23
  • Mounting: Surface mount technology (SMT)
  • Maximum Gate-Source Voltage: ±20V
  • Maximum Rds On: 250 mOhm @ 910mA and 10V
  • Applications: Consumer electronics and low power industrial applications
