IRLML6302TRPBF

Name: IRLML6302TRPBF
Brand: Infineon Technologies
SKU: 161516
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRLML6302TRPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	Trans MOSFET P-CH 20V 0.78A 3-Pin SOT-23 T/R / MOSFET P-CH 20V 780MA SOT-23
Datasheet	IRLML6302TRPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	20V
Continuous Drain Current at 25°C	780mA (Ta)
Drive Voltage (Max Rds On, Min Rds On)	2.7V, 4.5V
Gate-Source Threshold Voltage	1.5V @ 250μA
Max Gate Charge	3.6nC @ 4.45V
Max Input Capacitance	97pF @ 15V
Maximum Gate-Source Voltage	±12V
Power Dissipation (Max)	540mW (Ta)
Maximum Rds On at Id,Vgs	600 mOhm @ 610mA, 4.5V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	Micro3/SOT-23
Dimension	TO-236-3, SC-59, SOT-23-3
Win Source Part Number	017772-IRLML6302TRPBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Application Field	Used in Power Management
Family Name	IRLML6302
Introduction Date	January 22, 2004
ECCN	EAR99
Country of Origin	China, Philippines, Thailand
Halogen Free	Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian IRLML6302TRPBF CAD Model

Alternative Products

Description

The Infineon Technologies IRLML6302TRPBF is a P-Channel MOSFET transistor designed for use in power management applications.

Drain-Source Breakdown Voltage: 20V
Continuous Drain Current: 780mA @ 25°C
Maximum Power Dissipation: 540mW @ Ta
Package: Micro3/SOT-23
Maximum Rds On: 600 mOhm @ 610mA, 4.5V
Popularity: 53% in the open market
Packaging: Reel-TR
Mounting: SMD (SMT)
Application: Power management applications
