IRLS4030TRLPBF Infineon Technologies IRLS4030TRLPBF Real Image IRLS4030TRLPBF label picture IRLS4030TRLPBF real image10322
Same model may have multiple batches, images only for reference.
IRLS4030TRLPBF Infineon Technologies IRLS4030TRLPBF Real Image IRLS4030TRLPBF label picture IRLS4030TRLPBF real image10322
IRLS4030TRLPBF Infineon Technologies IRLS4030TRLPBF Real Image IRLS4030TRLPBF label picture IRLS4030TRLPBF real image10322
Same model may have multiple batches, images only for reference.

IRLS4030TRLPBF

Part No IRLS4030TRLPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 100V 180A D2PAK
Datasheet
IRLS4030TRLPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 180A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.5V @ 250μA
Max Gate Charge 130nC @ 4.5V
Max Input Capacitance 11360pF @ 50V
Maximum Gate-Source Voltage ±16V
Power Dissipation (Max) 370W (Tc)
Maximum Rds On at Id,Vgs 4.3 mOhm @ 110A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D2PAK
Dimension TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number 1047655-IRLS4030TRLPBF
Family Name IRLS4030
Introduction Date February 12, 2009
ECCN EAR99
Country of Origin China, Mexico, Republic of Korea
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IRLS4030TRLPBF CAD Model

Description

The Infineon Technologies 1047655-IRLS4030TRLPBF is a MOSFET transistor with a N-Channel polarity.

  • Power Dissipation (Max): 370W (Tc)
  • Continuous Drain Current: 180A (Tc) @ 25°C
  • Drain-Source Breakdown Voltage: 100V
  • Gate-Source Threshold Voltage: 2.5V @ 250μA
  • Maximum Gate Charge: 130nC @ 4.5V
  • Maximum Input Capacitance: 11360pF @ 50V
  • Case: D2PAK
  • Product Category: Discrete Semiconductor Products
  • Supply and Demand Status: Sufficient
