IRSM005-800MH

Part No IRSM005-800MH
Manufacturer Infineon Technologies
Catalog PMIC - Full, Half - Bridge Drivers
Description IC GATE DRIVER 40V QFN / Half Bridge Driver AC Motors, DC Motors, DC-DC Converters, General Purpose Power MOSFET 27-PQFN (7x8)
Datasheet
IRSM005-800MH Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs)>PMIC - Full, Half-Bridge Drivers
Mfr Infineon Technologies
Series µIPM™
Package Tray
Output Configuration Half Bridge
Applications AC Motors, DC Motors, DC-DC Converters, General Purpose
Interface Logic
Load Type Inductive, Capacitive
Technology Power MOSFET
Rds On (Typ) 2.7mOhm
Current - Output / Channel 80A
Voltage - Supply 10V ~ 20V
Voltage - Load 40V (Max)
Temperature Range - Operating 150°C (TJ)
Features Bootstrap Circuit
Fault Protection UVLO
Mounting SMD (SMT)
Package / Case 27-PowerVQFN
Supplier Device Package 27-PQFN (7x8)
Base Product Number IRSM005
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Names SP001549876,IFEINFIRSM005-800MH,2156-IRSM005-800MH
Standard Package 260
Win Source Part Number 1065674-IRSM005-800MH
Ultra Librarian 3D Model Ultra Librarian IRSM005-800MH CAD Model

Description

The Infineon Technologies IRSM005-800MH is a surface-mount device (SMD) electronic component that belongs to the Integrated Circuits (ICs)>PMIC - Full, Half-Bridge Drivers category. It has an interface of logic and a voltage - load of 40V (Max). The Win Source Part Number for this product is 1065674-IRSM005-800MH. It has a temperature range - operating of 150°C (TJ) and a load type of inductive, capacitive.
