TLE4276DV

Part No TLE4276DV
Manufacturer Infineon Technologies
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LINEAR VOLT TLE4276
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Voltage Regulators - Linear
Mfr Infineon Technologies
Package Bulk
Product Status Active
Output Configuration Positive
Output Type Adjustable
Number of Regulators 1
Voltage - Input (Max) 40V
Voltage - Output (Min/Fixed) 2.5V
Voltage - Output (Max) 20V
Voltage Dropout (Max) 0.5V @ 250mA
Current - Output 400mA
Current - Quiescent (Iq) 220 µA
Current - Supply (Max) 25 mA
PSRR 54dB (100Hz)
Control Features Inhibit
Protection Features Antisaturation, Over Temperature, Reverse Polarity, Short Circuit
Temperature Range - Operating -40°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case TO-252-5, DPak (4 Leads + Tab), TO-252AD
Supplier Device Package P-TO252-5-1
Standard Package 1 pcs
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 686790-TLE4276DV
Ultra Librarian 3D Model Ultra Librarian TLE4276DV CAD Model

Description

The 686790-TLE4276DV is a linear voltage regulator integrated circuit manufactured by Infineon Technologies. It falls under the category of Power Management (PMIC) in the electronic components industry. This product is designed to regulate voltage and provide a stable output. It has a current output capacity of 400mA and a maximum input voltage of 40V. The output voltage can be adjusted and has a minimum/fixed value of 2.5V. It is surface mountable and comes in a TO-252-5, DPak package. The temperature range for operating this product is from -40°C to 150°C. It has a PSRR (Power Supply Rejection Ratio) of 54dB @ 100Hz. The protection features of this voltage regulator include antisaturation, over temperature, reverse polarity, and short circuit protection. In terms of market availability, there is a 59% threat of fake products in the open market. The current quiescent (Iq) is 220 µA. The ECCN for this product is EAR99. The HTSUS code is 8542.39.0001. Overall, this product is currently active and widely used in various power management applications.

  • Manufacturer: Infineon Technologies
  • Category: Power Management (PMIC)
  • Current Output: 400mA
  • Maximum Input Voltage: 40V
  • Output Voltage: adjustable
  • Minimum/Fixed Output Voltage: 2.5V
  • Mounting: surface mountable
  • Package: TO-252-5, DPak
  • Temperature Range: -40°C to 150°C
  • PSRR (Power Supply Rejection Ratio): 54dB @ 100Hz
  • Protection Features: antisaturation, over temperature, reverse polarity, and short circuit protection
  • Threat of Fake Products: 59%
  • Current Quiescent (Iq): 220 µA
  • ECCN: EAR99
  • HTSUS Code: 8542.39.0001
  • Status: active
