ICL7660SCBAZ-T Real Image ICL7660SCBAZ-T real image4659
ICL7660SCBAZ-T Real Image ICL7660SCBAZ-T real image4659
Same model may have multiple batches, images only for reference.

ICL7660SCBAZ-T

Part No ICL7660SCBAZ-T
Manufacturer Intersil
Catalog PMIC - Voltage Regulators - DC DC Switching Regulators
Description IC REG SWTCHD CAP INV 45MA 8SOIC
Datasheet
ICL7660SCBAZ-T Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Intersil
Packaging Reel - TR
Status Active
Purpose Ratiometric
Topology Charge Pump
Output Type Fixed
Number of Outputs 1
Minimum Input Voltage 1.5V
Maximum Input Voltage 12V
Nominal Output Voltage (Min/Fixed) -Vin, 2Vin
Output Current 45mA
Frequency - Switching 10kHz to 35kHz
Synchronous Rectifier No
Temperature Range - Operating 0°C to 70°C (TA)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 017126-ICL7660SCBAZ-T
Family Name ICL7660S
Introduction Date March 29, 1999
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian ICL7660SCBAZ-T CAD Model

Description

The Intersil 017126-ICL7660SCBAZ-T is a fixed-output charge pump designed for integrated circuit applications.

  • Switching Frequency: 10kHz to 35kHz
  • Maximum Input Voltage: 12V
  • Nominal Output Voltage: -Vin, 2Vin
  • Minimum Input Voltage: 1.5V
  • Output Current: 45mA
  • Operating Temperature: 0°C to 70°C (TA)
  • Package: 8-SOIC
  • Status: Sufficient Supply
