The PS2501-1SM is a transistor output optoisolator with a photovoltaic output. It is designed for use in DC input applications and has a maximum forward current of 50mA. The forward voltage is typically 1.2V. The rise/fall time is 4μs/3μs, providing fast switching capabilities. This optoisolator has one channel and a voltage isolation of 5300Vrms, ensuring reliable signal transmission. The current transfer ratio is a minimum of 80% at 5mA and a maximum of 600% at 5mA. The maximum output voltage is 80V, and the Vce saturation is 300mV. The PS2501-1SM is surface mountable with a 4-SMD package. It operates in a temperature range of -30°C to 100°C, making it suitable for a variety of environments. This optoisolator is an active product from Isocom Components 2004 LTD.

• Maximum forward current: 50mA
• Forward voltage: 1.2V
• Rise/fall time: 4μs/3μs
• Channels: One
• Voltage isolation: 5300Vrms
• Current transfer ratio: Minimum 80% @ 5mA, Maximum 600% @ 5mA
• Maximum output voltage: 80V
• Vce saturation: 300mV
• Package: 4-SMD
• Temperature range: -30°C to 100°C
