The SR860L is a high-performance Schottky Barrier Diode manufactured by Jinan Jingheng (Group) Co., Ltd. This diode is designed for applications requiring high switching speeds and low forward voltage drop. Its robust construction ensures reliable operation in a variety of demanding environments.

Applications


• Switching Power Supplies: Used in power supplies to rectify AC voltage to DC voltage efficiently.

• Freewheeling Diodes: Protects inductive loads from voltage spikes by providing a path for current when the switch is turned off.

• Reverse Polarity Protection: Prevents damage to circuits by blocking current flow in the reverse direction.

• High-Frequency Rectification: Used in high-frequency circuits for efficient rectification.

• DC-DC Converters: Employed in DC-DC converters to improve efficiency and reduce losses.

Features


• High Surge Current Capability: Designed to withstand high surge currents without failure.

• Low Forward Voltage Drop: Minimizes power loss and improves efficiency.

• High Switching Speed: Enables efficient operation in high-frequency circuits.

• Guard Ring Structure: Improves voltage surge capabilities.

• Lead-Free Finish/RoHS Compliant: Complies with environmental standards.

Benefits


• Improved Efficiency: The low forward voltage drop reduces power loss, leading to higher overall efficiency.

• Enhanced Reliability: The high surge current capability and robust construction ensure reliable operation in demanding applications.

• Protection of Sensitive Components: Serves as a crucial protection component in different electrical circuit applications.

• Environmentally Friendly: RoHS compliant, making it suitable for environmentally conscious applications.

• Optimized Performance: The combination of high switching speed and low forward voltage drop allows for optimized performance in various circuits.

Additional Details

The SR860L typically comes in a DO-201AD package. Its maximum repetitive peak reverse voltage is usually around 60V, and its maximum average forward rectified current is approximately 8.0A. The forward voltage at a specified forward current and temperature is usually quite low, enhancing its efficiency. The operating junction temperature range is generally from -65°C to +150°C. Always refer to the manufacturer's datasheet for precise specifications and application guidelines to ensure correct and safe usage. This diode is designed to offer superior performance and reliability in a wide array of applications.
