GAL16V8D-15LJNI real image GAL16V8D-15LJNI Real Image
GAL16V8D-15LJNI real image GAL16V8D-15LJNI Real Image
Same model may have multiple batches, images only for reference.

GAL16V8D-15LJNI

Part No GAL16V8D-15LJNI
Manufacturer Lattice Semiconductor Corporation
Catalog Embedded - CPLDs (Complex Programmable Logic Devices)
Description High Performance E2CMOS PLD Generic Array Logic™
Datasheet
GAL16V8D-15LJNI Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Lattice Semiconductor Corporation
Series GAL16V8
Packaging Bulk
Part Status Obsolete(EOL)
Programmable Type EE PLD
Delay Time tpd(1) Max 15.0ns
Voltage Supply - Internal 4.5 V ~ 5.5 V
Number of Macrocells 8
Operating Temperature Range -40°C ~ 85°C (TA)
Mounting SMD
Package 20-LCC (J-Lead)
Manufacturer Package 20-PLCC (9x9)
Win Source Part Number 1176776-GAL16V8D-15LJNI
Manufacturer Homepage www.latticesemi.com
Family Name GAL16V8
Introduction Date July 23, 1996
ECCN EAR99
Country of Origin Indonesia, Malaysia, Philippines
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian GAL16V8D-15LJNI CAD Model

Description

The GAL16V8D-15LJNI is an obsolete (EOL) integrated circuit manufactured by Lattice Semiconductor Corporation.

  • Type: EE PLD (Programmable Logic Device)
  • Series: GAL16V8
  • Macrocells: 8
  • Operating Temperature Range: -40°C to 85°C (TA)
  • Suitable Applications: Embedded systems, video processing, and high-performance computing applications.
