LT1764AEQ-3.3#TRPBF - Low Dropout Positive Regulators

The LT1764AEQ-3.3#TRPBF is a high-performance, low dropout (LDO) positive regulator from Linear Technology, designed to provide a stable and reliable power supply with a fixed output voltage of 3.3V. This regulator is well-suited for applications requiring up to 3A of output current with a dropout voltage of only 340mV at full load.

With its low noise and fast transient response, the LT1764AEQ-3.3#TRPBF is an excellent choice for precision applications such as powering sensitive analog and digital circuits in mixed-signal environments. The device features a wide input voltage range from 2.7V to 20V, making it versatile for various applications, including battery-powered equipment, portable devices, and industrial machinery.

The LT1764AEQ-3.3#TRPBF comes in a robust TO-263 (DDPAK) package, which enhances its thermal performance and reliability. The regulator also includes several built-in protection features such as overcurrent protection, overtemperature protection, and reverse battery protection, ensuring the safety and longevity of the end application.

Key features of the LT1764AEQ-3.3#TRPBF include:

• Fixed Output Voltage: 3.3V
• Output Current: Up to 3A
• Low Dropout Voltage: 340mV at full load
• Wide Input Voltage Range: 2.7V to 20V
• Low Noise: 40µVRMS (10Hz to 100kHz)
• Fast Transient Response
• Stable with Low ESR, Ceramic Output Capacitors
• Built-in Protection Features:
  • Overcurrent Protection
  • Overtemperature Protection
  • Reverse Battery Protection
• Package: TO-263 (DDPAK)

Whether you're designing power supplies for sensitive communication equipment, high-end audio systems, or sophisticated medical devices, the LT1764AEQ-3.3#TRPBF provides a reliable and efficient solution that meets the stringent requirements of a wide range of applications.

By choosing the LT1764AEQ-3.3#TRPBF for your design, you can ensure a compact, robust, and high-performance power management solution that significantly enhances the overall stability and performance of your electronic systems.
