Product Overview: LT1936IMS8E#TRPBF

The LT1936IMS8E#TRPBF is a high-performance, fixed-frequency step-down switching regulator from Linear Technology, designed to deliver efficiency and reliability in a wide range of applications. This integrated circuit is suitable for converting a higher input voltage to a lower output voltage with a high level of accuracy and efficiency, making it an ideal choice for portable devices, industrial equipment, and automotive systems.

Key Features

• Adjustable Switching Frequency: The device offers a user-adjustable switching frequency from 300kHz to 2.2MHz, allowing designers to choose the optimal frequency for their application, balancing efficiency and component size.
• Wide Input Voltage Range: It operates from a wide input voltage range of 3.6V to 36V, accommodating a variety of power sources, from single-cell Li-Ion batteries to industrial supplies.
• Integrated 1.1A Switch: The LT1936IMS8E#TRPBF includes an internal 1.1A power switch, which simplifies the design and reduces external component count.
• Stable with Ceramic Capacitors: The regulator is stable with ceramic output capacitors, ensuring good transient response and minimizing output ripple.
• Low Dropout Operation: Its low dropout operation is beneficial for applications where the input voltage is close to the output voltage, maximizing efficiency.

Protection Features

• Over-Temperature Protection: The device incorporates over-temperature protection that safeguards the regulator from damage due to excessive heat.
• Current Limiting: Built-in current limiting prevents damage from over-current conditions, enhancing the durability and lifespan of the regulator.

Package and Temperature Range

The LT1936IMS8E#TRPBF is offered in a compact MSOP-8 package, which is ideal for space-constrained applications. It is designed to operate over a wide temperature range, ensuring reliable performance in various environmental conditions.

Applications

• Portable Electronics
• Automotive Power Systems
• Industrial Controls
• Point-of-Load Power Supplies

With its robust feature set and versatile performance characteristics, the LT1936IMS8E#TRPBF from Linear Technology stands out as a smart choice for designers seeking a compact, efficient, and reliable power management solution.
