LT1959IR#TRPBF - Robust High-Speed Synchronous Switching Regulator

The LT1959IR#TRPBF is a high-performance synchronous switching regulator designed by Linear Technology, which is now part of Analog Devices. This regulator is known for its robustness and efficiency, making it an ideal choice for a wide range of power supply applications. With its integrated features, the LT1959IR#TRPBF offers a compact and reliable solution for converting higher voltages to lower voltages with high efficiency.

Key Features

• High Efficiency: Capable of converting input voltages up to 36V down to lower output voltages while maintaining up to 95% efficiency, the LT1959IR#TRPBF is suitable for battery-operated devices and energy-sensitive applications.
• High-Speed Operation: With a switching frequency of 500kHz, this regulator allows for a smaller external inductor and capacitors, resulting in a compact power supply design.
• Adjustable Output Voltage: The output voltage can be adjusted from 1.25V to 20V, providing flexibility for various design requirements.
• Thermal Protection: It includes thermal shutdown to protect the device under extreme operating conditions.
• Current Mode Operation: The current mode control scheme ensures excellent line and load transient response and cycle-by-cycle current limiting for improved safety and reliability.
• Low Dropout Operation: The regulator's low dropout performance is ideal for applications where the input voltage is close to the output voltage.

Applications

The LT1959IR#TRPBF is versatile and can be used in various applications, including:

• Portable and battery-powered devices
• Telecommunications equipment
• Automotive power systems
• Industrial power supplies
• DC-DC converters

Quality and Reliability

Linear Technology ensures that the LT1959IR#TRPBF meets the highest standards of quality and reliability. The device is offered in a thermally enhanced 16-lead TSSOP package, which provides excellent thermal performance in a small footprint. Its robust design and built-in protection features make it a reliable choice for demanding environments where a stable and efficient power supply is critical.

Overall, the LT1959IR#TRPBF from Linear Technology is a powerful solution for designers looking to optimize their power supply designs with a high-speed, efficient, and reliable switching regulator.
