Products specifications

Categories Integrated Circuits (ICs)
Manufacturer Linear Technology
Packaging Reel package
Function Step-Down
Output Configuration Positive
Topology Buck
Output Type Adjustable
Number of Outputs 1
Input Voltage MIN 3.6V
Voltage Input MAX 33V
Output Voltage 0.79V
Output Voltage MAX 30V
Output Current 3.5A
Frequency - Switching 230kHz ~ 2.45MHz
Synchronous Rectifier No
Operating Temperature Range -40°C ~ 125°C (TJ)
Mounting SMD
Package 10-WFDFN Exposed Pad
Manufacturer Package 10-DFN (3x3)
Win Source Part Number 781354-LT3972EDD#TRPBF
Popularity Medium
Supply and Demand Status Limited
Family Name LT3972
Introduction Date September 18, 2008
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LT3972EDD#TRPBF CAD Model

Description

The LT3972EDD#TRPBF is an efficient, step-down DC/DC converter from Linear Technology, designed to meet the needs of a wide range of applications. This versatile component is capable of converting a higher input voltage to a lower output voltage with a high degree of efficiency, making it an ideal choice for portable devices, automotive applications, and industrial systems.

Key Features

  • Wide Input Voltage Range: The device can operate with input voltages from 3.6V to 20V, accommodating a variety of power sources and fluctuating supply conditions.
  • Adjustable Output Voltage: Users can set the output voltage from 0.79V to as high as the input voltage, providing flexibility for different circuit requirements.
  • High Efficiency: With its integrated 3.5A switch, the LT3972EDD#TRPBF can deliver efficiencies up to 93%, ensuring minimal heat generation and longer battery life in portable applications.
  • Compact Design: Housed in a small 10-pin DFN package (3mm x 3mm), this converter is designed for space-constrained applications.
  • Burst Mode® Operation: The device features Burst Mode operation, which reduces quiescent current under light loads, further enhancing battery life.
  • Thermal Protection: It comes with internal thermal shutdown protection, safeguarding the device from damage due to overheating.
  • Robust Performance: The LT3972EDD#TRPBF is designed to be rugged, with a wide temperature range and the ability to withstand harsh environments.

Applications

The flexibility and efficiency of the LT3972EDD#TRPBF make it suitable for a diverse array of applications, including but not limited to:

  • Automotive and industrial power systems
  • Portable and battery-powered equipment
  • Telecommunications and networking devices
  • Medical devices
  • Distributed power systems

In summary, the LT3972EDD#TRPBF from Linear Technology is a powerful, compact, and efficient solution for modern DC/DC conversion needs, providing reliable performance across a broad range of applications.
