The LT6107MPS5#TRPBF is a high-quality, high side current sense amplifier from Linear Technology, designed to monitor current in a variety of applications. This particular component is capable of precision current measurement with a minimal need for external components, making it a convenient choice for designers looking to streamline their designs.

Key Features

• Wide Input Voltage Range: The LT6107 is capable of functioning with an input voltage range from 4V up to 60V, making it versatile for use in systems with varying power levels.
• High Accuracy: It offers a precision over temperature with a maximum offset voltage of only 500µV, ensuring accurate current measurement across a range of conditions.
• Low Current Consumption: With a quiescent current of only 170µA, the LT6107 is ideal for power-sensitive applications.
• Flexible Gain Configuration: The device allows for a user-selectable gain by choosing external resistors, providing designers with flexibility to tailor the amplifier to their specific needs.
• Wide Operating Temperature Range: It operates over a temperature range from -40°C to 125°C, suitable for demanding environments.

Applications

The LT6107MPS5#TRPBF is well-suited for a wide range of applications, including, but not limited to:

• Automotive battery monitoring
• Power management systems
• Overcurrent protection
• Portable equipment
• Data acquisition systems

Package and Availability

The device is available in a small 5-lead SOT-23 package, marked with the part number LT6107MPS5#TRPBF, and is offered in tape and reel packaging for use in automated manufacturing environments. This packaging ensures safe handling and efficient assembly during the production process.

With its robust design and comprehensive features, the LT6107MPS5#TRPBF from Linear Technology stands out as a reliable choice for high side current sensing in a variety of high-performance applications.
