Product Overview: LT6700HVHS6-1 from Linear Technology

The LT6700HVHS6-1 is a high-performance, low-power comparator from Linear Technology, designed to provide precise voltage monitoring in a wide range of applications. This device is part of the LT6700 series, known for its reliability and versatility in various electronic circuits. The LT6700HVHS6-1, in particular, is engineered to handle higher voltages, making it suitable for systems that operate under more demanding conditions.

Key Features

• Dual Comparator: The LT6700HVHS6-1 includes two independent comparators, allowing for simultaneous monitoring of two separate voltage thresholds or signals.
• High Voltage Range: This device is capable of functioning with a supply voltage range from 2.5V up to 36V, or ±18V for split supplies, accommodating a variety of high-voltage applications.
• Low Power Consumption: With a quiescent current of just 6.5μA per comparator, the LT6700HVHS6-1 is an energy-efficient choice for battery-powered and portable devices.
• Internal Voltage References: Each comparator comes with a precise internal voltage reference, simplifying design and reducing external component count.
• Adjustable Hysteresis: Users can set the hysteresis level of the comparators to tailor the switching thresholds to specific application needs.
• Robust Output Stage: The output stage can directly drive loads, and is designed to be compatible with TTL and CMOS logic levels.

Applications

The LT6700HVHS6-1 is well-suited for a multitude of applications, including but not limited to:

• Battery monitoring
• Power supply control
• Threshold detection and signal processing
• Automotive electronics
• Portable and wireless devices

Package and Reliability

Encased in a compact 6-lead SOT-23 package, the LT6700HVHS6-1 is designed for space-constrained applications. The device is characterized for operation from -40°C to 125°C, ensuring reliable performance across a broad range of temperatures. With its robust design and Linear Technology's commitment to quality, the LT6700HVHS6-1 is a dependable component for critical and high-precision electronic systems.
