The LTC2900-1CDD is a versatile quad voltage monitor designed by Linear Technology, now part of Analog Devices, to ensure the reliability and stability of power supplies within electronic systems. This precision monitoring device is ideal for systems that require multiple supply voltages to operate correctly and safely.

Key Features

• Monitoring Capability: The LTC2900-1CDD can monitor up to four voltage points, which is essential for complex systems where multiple supply voltages need to be under scrutiny.
• Adjustable Thresholds: Users can set precise voltage thresholds for monitoring thanks to the external resistive dividers, providing flexibility and adaptability to various applications.
• Low Power Consumption: With its low operating current, this device is suitable for power-sensitive applications, ensuring minimal impact on the overall power budget of the system.
• Wide Operating Range: The device operates over a wide supply voltage range, accommodating different types of systems and power requirements.
• Output Indicator: The LTC2900-1CDD features a status output that indicates if any of the monitored voltages fall below their respective thresholds, providing an immediate alert to the system.
• Reset Timing Control: The built-in adjustable reset timeout period allows for controlled system restarts and recovery.

Applications

The LTC2900-1CDD is suitable for a variety of applications, including but not limited to:

• Computer Systems
• Network Servers
• Telecommunications Equipment
• Industrial Systems
• Medical Equipment

Product Specifications

The LTC2900-1CDD is packaged in a compact 10-lead DFN or MSOP, making it an excellent choice for space-constrained applications. Its precision and reliability are backed by Linear Technology's commitment to high-quality semiconductor solutions.

For more detailed specifications, reference designs, and application notes, customers are encouraged to visit the official product page or contact Linear Technology/Analog Devices directly.
