TPSMF4L36A Real Image TPSMF4L36A Real Image
Same model may have multiple batches, images only for reference.
TPSMF4L36A Real Image TPSMF4L36A Real Image
TPSMF4L36A Real Image TPSMF4L36A Real Image
Same model may have multiple batches, images only for reference.

TPSMF4L36A

Part No TPSMF4L36A
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS DIODE 36VWM 58.1VC SOD123FL
Datasheet
TPSMF4L36A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Estimated Pruduction Lead Time 48 Weeks
Features 58.1V Clamp 6.9A Ipp Tvs Diode Surface Mount SOD-123F
Manufacturer Littelfuse Inc.
Series Automotive, AEC-Q101, TPSMF4L
Package Reel - TR
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting Surface Mount
Package SOD-123F
Case / Package SOD-123F
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.10.0080
Other Part Number -TPSMF4L36A, F7526TR, F7526DKR, F7526CT
Quantity per package 3000
Popularity High
Supply and Demand Status Balance
Win Source Part Number 937502-TPSMF4L36A
Ultra Librarian 3D Model Ultra Librarian TPSMF4L36A CAD Model

Description

The TPSMF4L36A is a TVS diode from Littelfuse Inc. that belongs to the Automotive, AEC-Q101, TPSMF4L series.

  • Package: surface mount diode in a SOD-123F package
  • Clamp: 58.1V
  • Ipp: 6.9A
  • Operating Temperature Range: -55°C to 150°C (TJ)
  • Application: circuit protection device
