Maxim Integrated's MAX13035EETE+ Overview

The MAX13035EETE+ is a state-of-the-art level translator from Maxim Integrated, designed to provide seamless voltage level translation for mixed-signal environments. This device is particularly adept at interfacing between low-voltage digital signal processors or microcontrollers and higher voltage systems, making it an essential component for a broad range of applications.

Key Features

• Versatile Voltage Translation: The MAX13035EETE+ supports bidirectional level translation between 1.2V to 3.6V on the V<sub>L side and 1.65V to 5.5V on the V<sub>CC side, accommodating a wide variety of logic levels.
• High-Speed Operation: Engineered for high-speed performance, it is capable of translating signals at speeds up to 100Mbps, making it suitable for high-speed SPI, I2C, and other serial interfaces.
• Low Power Consumption: With a quiescent current of only 10µA (max) and a shutdown current of 1µA (max), it ensures minimal power draw when in idle or shutdown mode.
• Robust Protection Features: The device includes integrated 15kV ESD protection on the V<sub>L side, safeguarding the interface against electrostatic discharges and enhancing system reliability.

Applications

The MAX13035EETE+ is ideal for use in a variety of applications, including but not limited to:

• Cellular Phones
• GPS Systems
• Laptops and Portable Devices
• Industrial Control Interfaces
• Low-Voltage ASIC Level Translation

Package and Quality

Encased in a compact 16-pin TQFN package with an exposed pad, the MAX13035EETE+ saves valuable board space while ensuring efficient heat dissipation. It is specified over the extended -40°C to +85°C temperature range, catering to industrial requirements. Maxim Integrated's commitment to quality ensures that this level translator meets the highest standards, providing reliable performance in the most demanding situations.

Ordering and Availability

For those interested in integrating the MAX13035EETE+ into their designs, it is available for order from Maxim Integrated's distributors. Detailed specifications, datasheets, and additional resources can be found on the Maxim Integrated website to assist with integration and design considerations.
