MAX308ESE+

Part No MAX308ESE+
Manufacturer Maxim Integrated
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description IC MULTIPLEXER 8X1 16SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Active
Number of Circuits 1
Max On Resistance 100 Ohm
Channel-to-Channel Matching (ΔRon) 1.5 Ohm
Single Supply Voltage (V+) 5 V to 30 V
Dual Supply Voltage(V±) ±5 V to 20 V
Max Switch Time (Ton,Toff) 150ns, 150ns
Charge Injection 2pC
Channel Capacitance(CS off, CD off) 3pF, 26pF
Max Leakage Current (IS off) 750pA
Crosstalk -92dB @ 100kHz
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 16-SO
Win Source Part Number 142391-MAX308ESE+
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MAX308ESE+ CAD Model

Description

The MAX308ESE+ is a highly integrated analog multiplexer from Maxim Integrated, designed to deliver exceptional performance for a wide range of applications requiring precise signal routing. This versatile component is suitable for systems that necessitate low leakage currents and charge injection, making it ideal for data acquisition systems, test equipment, and battery-operated instruments.

Key Features

  • Multiple Configuration Options: The device can operate as an 8-channel single-ended multiplexer or a dual 4-channel differential multiplexer, offering flexibility in application design.
  • Low Power Consumption: With its CMOS technology, the MAX308ESE+ ensures minimal power usage, which is crucial for portable and battery-powered devices.
  • High Accuracy: The device boasts low charge injection and low leakage currents, which contribute to maintaining signal integrity and accuracy in sensitive analog applications.
  • Single Supply Operation: It can operate from a single +5V to +30V supply, or from dual supplies of ±4.5V to ±20V, providing versatility in different circuit environments.
  • ESD Protection: The MAX308ESE+ includes enhanced ESD protection, safeguarding the device from electrostatic discharges during handling and operation.

Applications

The MAX308ESE+ is adept for use in various applications where multiplexing of analog or digital signals is required. It is particularly useful in:

  • Data Acquisition Systems
  • Battery-Operated Equipment
  • Audio Signal Routing
  • Test Equipment
  • Communication Systems

Package and Quality

This component is packaged in a 16-pin narrow SO package, offering a compact footprint for space-constrained applications. Maxim Integrated is committed to maintaining high-quality standards, and the MAX308ESE+ is no exception, ensuring reliability and performance consistency for your critical design requirements.
