The MAX3221CUE is a high-quality integrated circuit from Maxim Integrated, designed to facilitate serial communication in a variety of electronic applications. This particular IC is a single transmitter/single receiver RS-232 and V.28 transceiver which operates from a single 3.0V to 5.5V power supply, making it highly versatile for use in portable and power-sensitive devices.

Key Features

• Low-Voltage Operation: The device operates efficiently across a voltage range from 3.0V to 5.5V, which is ideal for battery-operated and portable applications.
• Low-Power Consumption: It features a low-power shutdown mode that reduces power consumption and extends battery life in portable systems.
• AutoShutdown Plus™ Feature: The MAX3221CUE includes Maxim's unique AutoShutdown Plus feature, which automatically enters a low power shutdown state when the RS-232 cable is disconnected or the connected peripherals are turned off.
• High Data Rate: The device supports data rates up to 250kbps, making it suitable for high-speed serial communication.
• Integrated Charge Pump: The on-chip charge pump circuitry generates the necessary RS-232 voltage levels (+/-10V) from a single low-voltage supply, eliminating the need for multiple power sources.
• ESD Protection: The transceiver includes integrated electrostatic discharge (ESD) protection circuitry, which protects against ESD events exceeding ±15kV using the Human Body Model (HBM).

Applications

The MAX3221CUE is designed for applications that require reliable data transmission and reception under varying voltage conditions. It is commonly used in:

• Portable Computing Devices
• Battery-Powered Equipment
• Handheld Equipment
• Data Cable Extensions
• Point-of-Sale Systems

Package Information

The MAX3221CUE comes in a 16-pin TSSOP (Thin Shrink Small Outline Package) which is conducive for space-saving designs. Its compact form factor and the surface-mount package make it an excellent choice for modern, compact electronic assemblies.

Ordering Information

For ordering, the product is available under the part number MAX3221CUE. Additional options may be available for bulk orders or specific industrial requirements. It is recommended to consult the manufacturer's datasheets and product guides for detailed specifications and application notes.
