PS-35-12 Mean Well Enterprises Co., Ltd.
Same model may have multiple batches, images only for reference.

PS-35-12

Part No PS-35-12
Manufacturer Mean Well Enterprises Co., Ltd.
Catalog External/Internal (Off - Board) AC DC Converters
Description AC/DC CONVERTER 12V 36W / Open Frame AC DC Converters 1 Output 12V 90 ~ 264 VAC, 127 ~ 370 VDC Input
Datasheet
PS-35-12 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - External/Internal (Off-Board) - AC DC Converters
Mfr Mean Well Enterprises Co., Ltd.
Series PS-35 (35W)
Package Box
Product Status Obsolete
Type Open Frame
Number of Outputs 1
Voltage - Input 90 ~ 264 VAC, 127 ~ 370 VDC
Voltage - Output 1 12V
Current - Output 1 3 A
Power (Watts) 36W
Applications ITE (Commercial)
Voltage - Isolation 3 kV
Efficiency 81%
Temperature Range - Operating -20°C ~ 65°C (With Derating)
Features Adjustable Output, Universal Input
Mounting Type Chassis Mount
Size / Dimension 4.00" L x 2.00" W x 0.94" H (101.6mm x 50.8mm x 24.0mm)
Approval Agency CB, CE, cURus, TUV
Minimum Load Required No
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9510
Win Source Part Number 657011-PS-35-12
Ultra Librarian 3D Model Ultra Librarian PS-35-12 CAD Model

Description

The PS-35-12 is a 35W open frame AC-DC converter from the PS-35 series.

  • Designed for: external or internal power supplies in ITE (Commercial) applications.
  • Voltage Input Range: 90V to 264V AC and 127V to 370V DC
  • Voltage Output: 12V
  • Maximum Output Current: 3A
  • Dimensions: 4.00" L x 2.00" W x 0.94" H
  • Features: adjustable output and universal input
  • Efficiency: 81%
  • Operating Temperature: -20°C to 65°C (with derating)
  • Certifications: CB, CE, cURus, and TUV
