SI2302-TP Real Image SI2302-TP real image11026
Same model may have multiple batches, images only for reference.
SI2302-TP Real Image SI2302-TP real image11026
SI2302-TP Real Image SI2302-TP real image11026
Same model may have multiple batches, images only for reference.

SI2302-TP

Part No SI2302-TP
Manufacturer Micro Commercial Co
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 20V 3A SOT-23
Datasheet
SI2302-TP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Micro Commercial Co
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 3A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 2.5V, 4.5V
Gate-Source Threshold Voltage 1.2V @ 50μA
Max Gate Charge 10nC @ 4.5V
Max Input Capacitance 237pF @ 10V
Maximum Gate-Source Voltage ±8V
Power Dissipation (Max) 1.25W (Ta)
Maximum Rds On at Id,Vgs 72 mOhm @ 3.6A, 4.5V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23
Dimension TO-236-3, SC-59, SOT-23-3
Win Source Part Number 1095724-SI2302-TP
Popularity Medium
Supply and Demand Status Limited
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian SI2302-TP CAD Model

Description

The Micro Commercial Co SI2302-TP is an N-channel MOSFET that is designed to handle a maximum power dissipation of 1.25W.

  • Drain-Source Breakdown Voltage: 20V
  • Maximum Rds On: 72 mOhm @ 3.6A, 4.5V
  • Maximum Gate Charge: 10nC @ 4.5V
  • Maximum Input Capacitance: 237pF @ 10V
  • Package: SOT-23
  • Dimension: TO-236-3, SC-59, SOT-23-3
  • Quantity: 3k pcs
