Microchip Technology 24LC1025T-E/SN EEPROM

The 24LC1025T-E/SN is a high-performance, 1 Mbit serial Electrically Erasable Programmable Read-Only Memory (EEPROM) device from Microchip Technology. This integrated circuit is designed to provide a flexible and reliable non-volatile memory storage solution for advanced microcontroller-based systems. Its I²C interface allows for easy integration into a wide array of electronic applications.

Key Features

• Memory Size: The device features a 1024 Kbit (1 Mbit) memory capacity, providing ample space for data storage requirements.
• Interface: It utilizes a serial I²C (Inter-Integrated Circuit) bus, which ensures simple two-wire serial communication with microcontrollers and other devices.
• Speed: The EEPROM operates at clock frequencies up to 400 kHz (Fast Mode) and 1 MHz (Fast-Mode Plus), making it suitable for high-speed data transactions.
• Low Power Consumption: Designed for low-power consumption, it is an excellent choice for battery-operated and power-sensitive applications.
• Operating Voltage: The device supports a wide voltage range from 2.5V to 5.5V, providing flexibility for various system voltage requirements.
• Package: It comes in an 8-pin SOIC (SN) package, which is widely used and suitable for surface-mount technology (SMT).
• Temperature Range: The EEPROM is operational across the industrial temperature range of -40°C to +85°C, ensuring reliable performance under extreme conditions.

Applications

The 24LC1025T-E/SN is versatile and can be employed in a variety of applications including:

• Data storage for industrial control systems
• Configuration and calibration data retention
• Consumer electronics settings storage
• Automotive systems data backup
• Medical devices memory requirements

With its robust design and extensive features, the Microchip Technology 24LC1025T-E/SN EEPROM is a reliable choice for designers looking to enhance their systems with a durable and efficient non-volatile memory solution.
