Microchip Technology 24LC256T-I/MS

The 24LC256T-I/MS is a 256Kb (32K x 8) Serial Electrically Erasable PROM, capable of operation across a broad voltage range (2.5V to 5.5V). This device from Microchip Technology is a high-capacity EEPROM (Electrically Erasable Programmable Read-Only Memory) that provides designers with flexibility and performance in memory storage applications. It is particularly well-suited for advanced, high-volume applications where the large memory storage capacity is required.

One of the key features of the 24LC256T-I/MS is its I²C-compatible (2-wire) serial interface, which allows for easy integration into most microcontroller-based systems. This interface also supports a bidirectional data transfer protocol, which simplifies the process of reading from and writing to the memory.

The device is available in an 8-lead MSOP (Mini Small Outline Package) that is RoHS compliant, making it suitable for environmentally sensitive applications. This package type is known for its small footprint, which is ideal for space-constrained designs. The 24LC256T-I/MS is designed to work reliably in extended temperature ranges, making it appropriate for industrial and automotive applications where robustness is a critical factor.

Additional features of this EEPROM include a 64-byte page write buffer, which allows for faster write operations, and a self-timed erase/write cycle with auto-erase, ensuring data integrity during write operations. The device also includes a hardware write-protect pin to prevent inadvertent write operations or data corruption during power transitions.

With its low-power consumption and high endurance of over 1 million write cycles, the 24LC256T-I/MS is an excellent choice for data storage in applications that require frequent or long-term data updates. Moreover, its data retention is rated at over 200 years, ensuring that data stored in the device remains secure and intact over an extended period.

Overall, the Microchip Technology 24LC256T-I/MS EEPROM provides a reliable and convenient solution for complex applications requiring significant data storage, robust performance, and a high level of data security.
