Microchip Technology 2N6420 Bipolar Transistor

The 2N6420 from Microchip Technology is a robust NPN silicon bipolar junction transistor (BJT) designed for high-speed switching applications. This versatile component is commonly utilized in a range of electronic circuits, from consumer electronics to industrial systems, offering reliable performance in a compact package.

Key Features:

• Type: NPN
• Package: TO-39 metal canister, which provides excellent thermal performance and durability.
• Collector-Emitter Voltage (Vceo): 40V, which allows for a wide range of operations in different circuit configurations.
• Collector-Base Voltage (Vcbo): 60V, offering a good safety margin for various applications.
• Emitter-Base Voltage (Vebo): 6V, ensuring stable operation even in circuits with higher base currents.
• Collector Current (Ic): 500mA, suitable for driving moderate loads.
• Power Dissipation (Pd): 800mW, providing a good balance between power handling and size.
• DC Current Gain (hFE): 40 to 120, offering consistent amplification over a range of operating conditions.
• Transition Frequency (fT): 200MHz, making it ideal for high-speed switching and amplification tasks.

Applications:

The 2N6420 transistor is engineered for versatility and can be found in a multitude of applications such as:

• Switching regulators
• Motor controls
• Amplifier stages
• Signal processing
• Oscillators
• High-frequency circuits

Reliability and Quality:

Microchip Technology is known for its commitment to quality and reliability. The 2N6420 transistor is built to high standards, ensuring consistent performance and longevity in a variety of environmental conditions. It is a testament to Microchip's dedication to providing components that meet the rigorous demands of the electronics industry.

Whether you're designing a new circuit or replacing a component in an existing system, the 2N6420 from Microchip Technology is a solid choice for a reliable and efficient NPN transistor that will serve your needs well.
