The ATF1504AS-10JI84 is a high-performance, programmable logic device (PLD) from Microchip Technology's Atmel portfolio. This complex programmable logic device (CPLD) is part of the ATF15xxAS series, known for its versatility and efficiency in handling a wide range of digital logic functions.

Key Features

• High-Density Design: With 64 macrocells and 68 I/O pins, this device offers ample space for complex digital logic designs, making it suitable for a variety of applications in the industrial, automotive, and consumer electronics sectors.
• Speed Grade: The '-10' in the part number indicates a 10 ns maximum propagation delay, ensuring high-speed operation for time-sensitive applications.
• Package Type: The 'JI84' suffix denotes a 84-pin PLCC (Plastic Leaded Chip Carrier) package, which is widely used for surface mount technology and provides a compact footprint for space-constrained applications.
• EEPROM Technology: Utilizing Electrically Erasable Programmable Read-Only Memory (EEPROM) technology allows for in-system programmability and reprogrammability, offering flexibility for design iterations and updates.
• Low Power Consumption: The device is designed for low power operation, which is crucial for battery-powered and energy-sensitive applications.
• Security Features: The ATF1504AS-10JI84 includes security features to protect the intellectual property of the design and prevent unauthorized access or copying.

Applications

The versatility of the ATF1504AS-10JI84 makes it an ideal choice for a broad range of applications. It is commonly used in:

• Automotive control systems
• Industrial automation
• Telecommunication infrastructure
• Consumer electronics
• Power management systems

As a product of Microchip Technology, a leading provider of smart, connected, and secure embedded control solutions, the ATF1504AS-10JI84 is backed by robust support and the company's reputation for quality and reliability.

Conclusion

The ATF1504AS-10JI84 CPLD from Microchip Technology is a powerful and flexible solution for designers looking to implement custom logic functions with high-speed performance and low power consumption. Its in-system programmability and security features make it a secure and adaptable choice for modern electronic applications.
