MCP8026T-115E/PT Microchip Technology – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

MCP8026T-115E/PT

Part No MCP8026T-115E/PT
Manufacturer Microchip Technology
Catalog PMIC - Motor Drivers, Controllers
Description IC MOTOR DRIVER 6V-28V 48TQFP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Motor Type - AC, DC Brushless DC (BLDC)
Function Controller - Commutation, Direction Management
Output Configuration Pre-Driver - Half Bridge (3)
Interface PWM
Technology NMOS, PMOS
Applications General Purpose
Voltage - Supply 6V ~ 28V
Temperature Range - Operating -40°C ~ 150°C (TA)
Mounting Type Surface Mount
Case / Package 48-TQFP Exposed Pad
Supplier Device Package 48-TQFP-EP (7x7)
Package Tape & Reel
Supply and Demand Status Shortage
Win Source Part Number 1541411-MCP8026T-115E/PT
Ultra Librarian 3D Model Ultra Librarian MCP8026T-115E/PT CAD Model
