34825-0200 Real Image
Same model may have multiple batches, images only for reference.

34825-0200

Part No 34825-0200
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Mini50 Unsealed Vertical Header, Dual Row, 20 Circuit, Polarization Option A, Black, Tray
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Contact Material Brass
Contact Plating Tin
Country of Origin CN
Current Rating 4 A
Gender Male
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Mount Through Hole
Number of Circuits 20
Number of Contacts 20
Number of Pins 20
Number of Rows 2
Orientation Vertical
Plating Tin
REACH SVHC Unknown
RoHS Compliant
Termination Through Hole
Win Source Part Number 997138-34825-0200
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 34825-0200 CAD Model

Description

This male connector is manufactured by Molex, LLC and is made of high-quality brass material.

  • Material: Brass
  • Termination: Through hole
  • Contact Plating: Tin
  • Current Rating: 4A
  • Circuits: 20
  • RoHS Compliant: Yes
  • Orientation: Vertical
  • Category: Circular Connectors
