35022-0002 Real Image
Same model may have multiple batches, images only for reference.

35022-0002

Part No 35022-0002
Manufacturer Molex, LLC
Catalog Circular Connectors
Description 2.50mm Pitch, Board-In Crimp Housing, Single Row, Right-Angle and Vertical, 2 Circuits, Natural
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Contact Gender Male
Country of Origin US
Depth 5.9 mm
Gender Female
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Housing Material Nylon
Length 6 mm
Number of Contacts 2
Number of Positions 2
Number of Rows 1
Orientation Straight
Pitch 2.5 mm
Radiation Hardening No
REACH SVHC No SVHC
RoHS Compliant
Schedule B 8536695050, 8536695050
Width 2.95 mm
Win Source Part Number 1146437-35022-0002
Categories Circular Connectors
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 35022-0002 CAD Model

Description

The Molex 1146437-35022-0002 is a straight orientation circular connector that has a pitch of 2.5 mm and a length of 6 mm.

  • Orientation: Straight
  • Pitch: 2.5 mm
  • Length: 6 mm
  • Gender: Female
  • Housing Material: Nylon
  • RoHS Compliant: Yes
  • Supply: Limited
  • Win Source Part Number: 1146437-35022-0002
