The 1038641-43045-2001 from Molex, LLC is a high-quality circular connector housing that is ideal for a range of applications.

• Positions: 20
• Pitch: 3 mm
• Connector Type: Plug, socket
• Rows: 2
• Row Spacing: 3 mm
• Termination: Through-hole
• Contact Material: Brass
• Voltage Rating: 250 V
• Current Rating: 5 A
• Housing Material: Thermoplastic
• Circuits: 20
• Orientation: Right angle
• Contact Plating: Gold
• Contact Resistance: 10 mΩ
• Plating: Tin
• Package: Tray
• Halogen Rating: Low halogen
• Maximum Operating Temperature: 105 °C
• Minimum Operating Temperature: -40 °C
• Maximum Voltage Rating (DC): 250.25 kV
• Glow Wire Compliant: Yes
• Alternative Parts: 5-794682-0, 43045-2023, 43045-2402, 43045-2401, 5499786-4, 5-103166-8, 5499913-40430452001, and 430452001
• Country of Origin: US
• ROHS Compliant: Yes
