48258-0001 Real Image
Same model may have multiple batches, images only for reference.

48258-0001

Part No 48258-0001
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Power RCP 8Power/36Signal POS Solder RA Thru-Hole 1Port
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Connector Type USB
Contact Material Brass
Contact Plating Gold
Country of Origin HK
Current Rating 1 A
Gender Female
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Maximum Operating Temperature 85 °C
Min Operating Temperature -25 °C
Mount Through Hole
Number of Circuits 4
Number of Contacts 4
Number of Ports 1
Number of Rows 1
Orientation Right Angle
Pitch 2.5 mm
Plating Tin
Radiation Hardening No
REACH SVHC No SVHC
RoHS Compliant
Termination Solder
Voltage Rating (AC) 250 V
Win Source Part Number 1033705-48258-0001
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 48258-0001 CAD Model

Description

The 1033705-48258-0001 USB connector from Molex, LLC is a 4-contact, right angle female connector with a pitch of 2.5mm.

  • Contacts: 4
  • Orientation: Right Angle
  • Gender: Female
  • Pitch: 2.5mm
  • Contact Plating: Gold
  • Plating: Tin
  • Construction: Low Halogen
  • RoHS: Compliant
  • Maximum Operating Temperature: 85°C
  • Mounting Style: Through-Hole
