Same model may have multiple batches, images only for reference.
53254-0570 Real Image
Same model may have multiple batches, images only for reference.

53254-0570

Part No 53254-0570
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description NEW 2.0 WTB WAFER ASSY RA 5CKT  /  Connector Header position
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Molex
Series *
Package Box
MSL Level Vendor Undefined
REACH Status REACH info available upon request
ECCN EAR99
HTSUS 8536.69.4040
Other Names 2266-53254-0570
Standard Package 1
Win Source Part Number 1170617-53254-0570
Ultra Librarian 3D Model Ultra Librarian 53254-0570 CAD Model

Description

The Molex 1170617-53254-0570 is a rectangular connector header with male pins. The connector has a package of one and is an alternative part for 0532540570, 53254-0570.., and 532540570.

  • Connector Type: Rectangular Header
  • Gender: Male Pins
  • Package Quantity: One
  • Alternative Parts: 0532540570, 53254-0570, 532540570
  • RoHS: Compliant
  • ECCN: EAR99
  • Manufacturer: Molex LLC
  • Popularity: Medium
  • REACH: Available upon Request
  • HTSUS: 8536.69.4040
  • Other Identifier: 2266-53254-0570
