Part No 87678-1001
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn SATA RCP 15Power/7Signal POS 1.27mm Solder ST Thru-Hole 22 Terminal 1 Port Tray
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Connector Type Receptacle, SATA
Contact Material Copper
Contact Plating Gold
Country of Origin SG
Current Rating 1.5 A
Depth 5 mm
Housing Material Polymer
Lead Free Yes
Lead Pitch 1.27 mm
Length 42.73 mm
Maximum Operating Temperature 105 °C
Min Operating Temperature -40 °C
Mount Through Hole
Number of Circuits 22
Number of Contacts 22
Number of Ports 1
Number of Positions 22
Number of Rows 1
Number of Terminals 22
Orientation Right Angle, Vertical
Pitch 1.27 mm
Plating Tin
RoHS Compliant
Termination Solder
Voltage Rating (DC) 30 V
Win Source Part Number 1041284-87678-1001
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 87678-1001 CAD Model

Description

The Molex 1041284-87678-1001 is a solder termination type connector designed for use with SATA receptacle.

  • Termination Type: solder
  • Application: SATA receptacle
  • Pitch: 1.27 mm
  • Positions: 22
  • Current Rating: 1.5 A
  • Voltage Rating: 30 VDC
  • Supply and Demand Status: shortage
  • Maximum Operating Temperature: 105 degrees Celsius
  • RoHS Compliant: yes
  • Lead-Free: yes
  • Housing Material: polymer
  • Contact Plating: gold
  • Category: circular connectors - housings
