56T300C

Part No 56T300C
Manufacturer Murata Power Solutions Inc.
Catalog Current Sense Transformers
Description CURR SENSE XFMR 10A T/H
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Frequency Range 20kHz ~ 200kHz
Type Non-Invasive (Solid Core)
Current Rating (Amps) 10 A
Current Ratio 300CT:1
DC Resistance (DCR) 5.73Ohm Primary, 8.59Ohm Secondary
Mounting Type Through Hole
Size / Dimension 0.661" L x 0.350" W (16.79mm x 8.89mm)
Height - Seated (Max) 0.795" (20.19mm)
Termination Style PC Pin
Package Box
Supply and Demand Status Shortage
Win Source Part Number 1545047-56T300C
Ultra Librarian 3D Model Ultra Librarian 56T300C CAD Model

Description

N
