Same model may have multiple batches, images only for reference.

49330SC

Name: 49330SC
Brand: Murata Power Solutions Inc.
SKU: 1327374
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	49330SC
Manufacturer	Murata Power Solutions Inc.
Catalog	Fixed Inductors
Description	FIXED IND 33UH 2.9A 60 MOHM SMD / 33 µH Shielded Wirewound Inductor 2.9 A 60mOhm Max Nonstandard, 4 Lead
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Manufacturer	Murata Power Solutions Inc.
Packaging	Reel - TR
Type	Wirewound
Inductance	33 µH
Tolerance	±20%
Current Rating (Amps)	2.9 A
Shielding	Shielded
DC Resistance (DCR)	60mOhm Max
Q @ Freq	51 @ 1MHz
Frequency - Self Resonant	10MHz
Temperature Range - Operating	-40°C ~ 85°C
Inductance Frequency - Test	10 kHz
Mounting	Surface Mount
Case / Package	Nonstandard, 4 Lead
Size / Dimension	0.480" L x 0.480" W (12.20mm x 12.20mm)
Height - Seated (Max)	0.315" (8.00mm)
Base Product Number	49
RoHS Status	ROHS3 Compliant
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.4000
Other Part Number	49330SC-ND,811-3622-6,811-3622-2,811-3622-1
Standard Package	500
Win Source Part Number	1327374-49330SC
Ultra Librarian 3D Model	Ultra Librarian 49330SC CAD Model

Alternative Products

Description

The Murata Power Solutions Inc. 33 µH Fixed Inductor is a wirewound type inductor with a shielding feature.

Dimension: 0.480" L x 0.480" W (12.20mm x 12.20mm)
Height: 0.315" (8.00mm)
Inductance: 33 µH
Tolerance: ±20%
Q @ Freq: 51 @ 1MHz
Frequency Self-Resonant: 10MHz
DC Resistance (DCR): 60mOhm Max
Current Rating: 2.9 A
Operating Temperature: -40°C to 85°C
Case/Package: Non-standard, 4-lead
ROHS3 Compliant: Yes
REACH Unaffected: Yes
