BAV23S,215

Part No BAV23S,215
Manufacturer Nexperia USA Inc.
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY GP 200V 225MA SOT23 / Diode Switching 250V 0.225A Automotive 3-Pin TO-236AB T/R
Datasheet
BAV23S,215 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel package
Diode Configuration 1 Pair Series Connection
Diode Type Standard
Voltage - DC Reverse (Vr) (Maximum) 200V
Current - Average Rectified (Io) (per Diode) 225mA (DC)
Voltage - Forward (Vf) (Maximum) @ If 1V @ 100mA
Speed Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 50ns
Current - Reverse Leakage @ Vr 100nA @ 200V
Operating Temperature - Junction 150°C (Maximum)
Mounting SMD
Package TO-236-3, SC-59, SOT-23-3
Manufacturer Package TO-236AB (SOT23)
Win Source Part Number 769691-BAV23S,215
Popularity Medium
Supply and Demand Status Limited
Family Name BAV23S
Introduction Date April 01, 1996
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2024
Ultra Librarian 3D Model Ultra Librarian BAV23S,215 CAD Model

Description

The Nexperia USA Inc. BAV23S,215 is a standard diode with a reverse recovery time of 50ns.

  • Diode Type: Standard
  • Reverse Recovery Time: 50ns
  • Reverse Leakage Current: 100nA @ 200V
  • Maximum Junction Operating Temperature: 150°C
  • Diode Configuration: One pair series connection
  • Package: TO-236-3, SC-59, SOT-23-3
  • Mounting Type: SMD
  • Forward Voltage: 1V @ 100mA
  • DC Current Average Rectified: 225mA per diode
  • Maximum DC Reverse Voltage: 200V
  • Maximum Input Capacitance: 1523pF @ 25V
  • Series: BAV23S
  • Halogen-Free: Yes
  • Supply and Demand Status: Limited
