PSMN013-100YSEX Real Image PSMN013-100YSEX Real Image1 PSMN013-100YSEX Real Image2
PSMN013-100YSEX Real Image PSMN013-100YSEX Real Image1 PSMN013-100YSEX Real Image2
Same model may have multiple batches, images only for reference.

PSMN013-100YSEX

Part No PSMN013-100YSEX
Manufacturer Nexperia USA Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 100V 82A LFPAK56
Datasheet
PSMN013-100YSEX Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Estimated Pruduction Lead Time 26 Weeks
Features N-Channel 100 V 82A (Tj) 238W (Tc) Surface Mount LFPAK56, Power-SO8
Manufacturer Nexperia USA Inc.
Package Reel - TR
Operating Temperature Range -55°C ~ 175°C (TJ)
Mounting Surface Mount
Package SC-100, SOT-669
Case / Package LFPAK56, Power-SO8
Family Name PSMN013
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Other Part Number 568-10284-1-ND, 568-10284-2-ND, 1727-1129-2, 568-10284-1, 568-10284-2, PSMN013-100YSEX-ND, 1727-1129-1, 1727-1129-6, 568-10284-6-ND, 568-10284-6, 934067544115
Quantity per package 1500
Popularity High
Supply and Demand Status Balance
Win Source Part Number 930910-PSMN013-100YSEX
Ultra Librarian 3D Model Ultra Librarian PSMN013-100YSEX CAD Model

Description

The PSMN013-100YSEX is a N-Channel MOSFET manufactured by Nexperia USA Inc.

  • Popularity: High
  • Supply and Demand Status: Balanced
  • Current Rating: 82A
  • On-Resistance: 1.3mΩ
