PSMN1R4-40YLDX Real Image PSMN1R4-40YLDX Real Image
Same model may have multiple batches, images only for reference.
PSMN1R4-40YLDX Real Image PSMN1R4-40YLDX Real Image
PSMN1R4-40YLDX Real Image PSMN1R4-40YLDX Real Image
Same model may have multiple batches, images only for reference.

PSMN1R4-40YLDX

Part No PSMN1R4-40YLDX
Manufacturer Nexperia USA Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 40V 100A LFPAK / Trans MOSFET N-CH 40V 100A 5-Pin(4+Tab) LFPAK T/R
Datasheet
PSMN1R4-40YLDX Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel package
Channel Type Type N
Technology MOSFET
Drain Source Voltage 40V
Current - Continuous Drain (Id) @ 25°C 100A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Vgs(th) (Maximum) @ Id 2.2V @ 1mA
Gate Charge (Qg) (Maximum) @ Vgs 96nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds 6661pF @ 20V
Vgs (Maximum) ±20V
Power Dissipation (Maximum) 238W (Tc)
Rds On (Maximum) @ Id, Vgs 1.4 mOhm @ 25A, 10V
Operating Temperature Range -55°C ~ 175°C (TJ)
Mounting SMD
Manufacturer Package LFPAK56, Power-SO8
Package SC-100, SOT-669
Win Source Part Number 792618-PSMN1R4-40YLDX
Popularity Medium
Supply and Demand Status Limited
Family Name PSMN1R4-40YLD
Introduction Date May 05, 2014
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2030
Ultra Librarian 3D Model Ultra Librarian PSMN1R4-40YLDX CAD Model

Description

The Nexperia USA Inc.The supply and demand status is limited. Nexperia USA Inc.

  • Current - Continuous Drain (Id): 100A (Tc) @ 25°C
  • Operating Temperature: -55°C to 175°C (TJ)
  • Package: SC-100, SOT-669
  • Mounting Type: SMD
  • Technology: MOSFET
  • Family Name: PSMN1R4-40YLD
  • Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
  • Channel Type: N
  • Drain Source Voltage: 40V
  • Vgs(th) (Maximum) @ Id: 2.2V @ 1mA
  • Gate Charge (Qg) (Maximum) @ Vgs: 96nC @ 10V
  • Input Capacitance (Ciss) (Maximum) @ Vds: 6661pF @ 20V
  • Vgs (Maximum): ±20V
  • Power Dissipation (Maximum): 238W (Tc)
  • Rds On (Maximum) @ Id, Vgs: 1.4 mOhm @ 25A, 10V
  • Alternative Parts (Cross-Reference): STK224N4F7AG, STK184N4F7AG, NTMYS1D2N04CLTWG, PSMN1R4-40YLD
  • Introduction Date: May 05, 2014
  • Estimated EOL Date: 2030
  • ECCN: EAR99
  • Halogen Free: Compliant
