NJG1684ME2-TE1 New Japan Radio NJG1684ME2-TE1 real image NJG1684ME2-TE1 label picture
NJG1684ME2-TE1 New Japan Radio NJG1684ME2-TE1 real image NJG1684ME2-TE1 label picture
Same model may have multiple batches, images only for reference.

NJG1684ME2-TE1

Part No NJG1684ME2-TE1
Manufacturer Nisshinbo Micro Devices Inc.
Catalog RF Switches
Description IC RF SWITCH SP4T 2.7GHZ 12EQFN
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF and Wireless - RF Switches
Mfr Nisshinbo Micro Devices Inc.
Package Tape & Reel
Product Status Active
RF Type CDMA, GSM, LTE, UMTS
Circuit SP4T
Frequency Range 2.7GHz
Isolation 25dB
Insertion Loss 0.35dB
Test Frequency 2.7GHz
IIP3 70dBm
Features DC Blocked
Impedance 50Ohm
Voltage - Supply 2.375V ~ 5V
Temperature Range - Operating -40°C ~ 85°C
Package / Case 12-XFQFN Exposed Pad
Supplier Device Package 12-EQFN (1.8x1.8)
Base Product Number NJG1684
Standard Package 3,000 pcs
Win Source Part Number 759118-NJG1684ME2-TE1
Ultra Librarian 3D Model Ultra Librarian NJG1684ME2-TE1 CAD Model

Description

The NJG1684ME2-TE1 is a RF switch integrated circuit designed for use in RF and wireless applications.

  • Type: SP4T (Single Pole Four Throw) switch
  • Frequency Range: 2.7GHz
  • Impedance: 50Ohm
  • Features: DC blocking
  • Insertion Loss: 0.35dB
  • Isolation: 25dB
  • RF Types Compatibility: CDMA, GSM, LTE, and UMTS
  • Voltage Supply: 2.375V to 5V
  • Temperature Range: -40°C to 85°C
  • Package: 12-XFQFN Exposed Pad
