NRF24L01 Nordic Semiconductors
Same model may have multiple batches, images only for reference.

NRF24L01

Part No NRF24L01
Manufacturer Nordic Semiconductors
Catalog RF Transceiver ICs
Description IC RF TXRX ISM>1GHZ 20VFQFN / IC RF TxRx Only General ISM > 1GHz 2.4GHz 20-VFQFN Exposed Pad
Datasheet
NRF24L01 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF and Wireless - RF Transceiver ICs
Mfr Nordic Semiconductors
Package Tray
Product Status Active
Programmable Not Verified
Type TxRx Only
RF Family/Standard General ISM > 1GHZ
Modulation GFSK
Frequency 2.4GHz
Data Rate (Max) 2Mbps
Power - Output 0dBm
Sensitivity -85dBm
Serial Interfaces SPI
Voltage - Supply 1.9V ~ 3.6V
Current - Receiving 11.1mA ~ 12.3mA
Current - Transmitting 7mA ~ 11.3mA
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Package / Case 20-VFQFN Exposed Pad
Supplier Device Package 20-QFN (4x4)
Base Product Number NRF24
Standard Package 490 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 259398-NRF24L01
Ultra Librarian 3D Model Ultra Librarian NRF24L01 CAD Model

Description

The NRF24L01 is a versatile RF transceiver IC designed for wireless communication applications.

  • Frequency: 2.4GHz
  • Functionality: transmit and receive
  • Power Output: 0dBm
  • Sensitivity: -85dBm
  • Data Rate: up to 2Mbps
  • Modulation: GFSK
  • Voltage Supply Range: 1.9V to 3.6V
  • Temperature Range: -40°C to 85°C
  • Mounting Type: surface mountable
  • Package: 20-VFQFN exposed pad
  • Standard Package Size: 490 pcs
  • Packaging: tray packaging
  • Solution: reliable and cost-effective solution for wireless communication applications
