NRF51802-QFAA-R Nordic Semiconductors
Same model may have multiple batches, images only for reference.

NRF51802-QFAA-R

Part No NRF51802-QFAA-R
Manufacturer Nordic Semiconductors
Catalog RF Transceiver ICs
Description BLUETOOTH LOW ENERGY AND 2.4 GHZ
Datasheet
NRF51802-QFAA-R Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF and Wireless - RF Transceiver ICs
Mfr Nordic Semiconductors
Series nRF51
Package Tape & Reel
Product Status Active
Programmable Not Verified
Type TxRx Only
RF Family/Standard Bluetooth
Protocol Bluetooth v4.1
Modulation GFSK
Frequency 2.4GHz
Data Rate (Max) 2Mbps
Power - Output 4dBm
Sensitivity -94dBm
Memory Size 256kB Flash, 16kB RAM
Serial Interfaces I2C, SPI, UART, USB
GPIO 31
Voltage - Supply 1.8V ~ 3.6V
Current - Receiving 8.7mA ~ 13.4mA
Current - Transmitting 4.7mA ~ 16mA
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Package / Case 48-VFQFN Exposed Pad
Supplier Device Package 48-QFN (6x6)
Base Product Number NRF51802
Standard Package 3,000 pcs
REACH Status REACH Unaffected
Win Source Part Number 740531-NRF51802-QFAA-R
Ultra Librarian 3D Model Ultra Librarian NRF51802-QFAA-R CAD Model

Description

The nRF51802-QFAA-R is a TxRx Only RF Transceiver IC from Nordic Semiconductors.

  • Manufacturer: Nordic Semiconductors
  • Frequency: 2.4GHz
  • Protocol: Bluetooth v4.1
  • Package: 48-VFQFN Exposed Pad
  • Memory: 256kB Flash, 16kB RAM
  • Power Output: 4dBm
  • Sensitivity: -94dBm
  • Interfaces: I2C, SPI, UART, USB
  • Voltage Supply: 1.8V to 3.6V
  • Operating Temperature: -40°C to 85°C
  • Product Status: Active
