Product Overview: 74HCT1G02GV from NXP

The 74HCT1G02GV is a high-speed Si-gate CMOS device from NXP Semiconductors, designed to deliver the logic functionality of a single 2-input NOR gate. This product is part of the 74HC(T) family, which is well-known for its compatibility with TTL (Transistor-Transistor Logic) levels, making it suitable for interfacing with standard 5V TTL integrated circuits. The 74HCT1G02GV variant is characterized for operation from -40°C to +125°C, ensuring reliable performance across a wide range of environmental conditions.

Encased in a compact SOT-753 (SC-74A) surface-mount package, the 74HCT1G02GV is optimized for space-constrained applications where board real estate is at a premium. The small footprint of this device does not compromise its functionality or performance, providing the same logical operation as its larger counterparts.

Key Features:

• Logic Type: 2-input NOR gate
• Package: SOT-753 (SC-74A)
• Supply Voltage Range: 4.5V to 5.5V
• High Noise Immunity: Ensures stable operation in electrically noisy environments
• High-Speed Performance: Fast propagation delays compatible with high-frequency applications
• Low Power Consumption: Suitable for battery-operated devices
• Temperature Range: Operational from -40°C to +125°C
• TTL-Compatible: Can be interfaced with TTL logic levels
• Compliance: Compliant with JEDEC standard no. 7A

The 74HCT1G02GV is designed for use in a wide array of electronic circuits, including but not limited to: logic synthesis, signal gating, and function generation. Its high noise immunity and low power consumption make it an excellent choice for use in portable electronics, where power efficiency and robust performance are essential.

Manufactured by NXP, a trusted leader in semiconductor solutions, the 74HCT1G02GV is a testament to the company's commitment to providing high-quality, reliable components for the electronics industry. Whether you are designing consumer electronics, industrial control systems, or automotive applications, the 74HCT1G02GV offers a versatile and dependable solution for your logic gate needs.
