The IP4776CZ38 is a cutting-edge solution from NXP Semiconductors designed for the protection and enhancement of high-definition multimedia interface (HDMI) and DisplayPort signal integrity. This state-of-the-art integrated circuit is engineered to safeguard sensitive high-speed interfaces from electrostatic discharge (ESD) and other voltage-induced damages, ensuring the reliability and longevity of consumer electronics such as high-definition televisions, gaming consoles, and personal computers.

Key Features

• ESD Protection: The IP4776CZ38 is equipped with robust ESD protection circuitry, capable of withstanding ESD strikes in accordance with the IEC 61000-4-2 standard, thus providing superior safeguarding for HDMI and DisplayPort interfaces.
• Signal Integrity Preservation: It incorporates advanced technology to maintain signal integrity for high-speed differential lines, ensuring optimal performance for video and audio data transmission.
• Integrated Termination Resistors: This device includes integrated termination resistors for HDMI and DisplayPort interfaces, which simplifies PCB design and reduces external component requirements.
• Low Capacitance Design: The low capacitance design of the IP4776CZ38 minimizes signal attenuation, allowing for the support of high-bandwidth signals without compromising quality.

Applications

The versatility of the IP4776CZ38 makes it an ideal choice for a wide range of applications, including:

• High-definition televisions (HDTVs)
• Digital video recorders (DVRs)
• Blu-ray players
• Gaming consoles
• Personal computers and laptops
• Professional video equipment

Technical Specifications

The IP4776CZ38 boasts a comprehensive set of technical specifications that ensure its performance in demanding environments:

• Package: TSSOP38
• Operating Temperature Range: -40°C to +85°C
• Compliance with HDMI 1.3, HDMI 1.4, HDMI 2.0, and DisplayPort standards

With its robust protection features and ability to preserve signal integrity, the IP4776CZ38 from NXP is an essential component for manufacturers and designers who demand the highest level of performance and protection for their high-definition multimedia products.
