LM75B

Part No LM75B
Manufacturer NXP / Nexperia
Description Digital temperature sensor and thermal watchdog
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer NXP
Win Source Part Number 1200693-LM75B
Manufacturer Homepage www.nxp.com
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Computers & Computer Peripherals, Industrial
Ultra Librarian 3D Model Ultra Librarian LM75B CAD Model

Description

NXP LM75B Digital Temperature Sensor

The NXP LM75B is a precision integrated circuit temperature sensor that plays a critical role in system temperature monitoring and management. Designed to be highly accurate and easy to interface with, the LM75B offers a standard I2C-bus interface, which makes it compatible with a vast array of microcontrollers and embedded systems.

This advanced temperature sensor provides a digital output that corresponds to the temperature of the device, with a range from -55°C to +125°C and an accuracy of ±2°C over the range of -25°C to +100°C, and ±3°C over the range of -55°C to +125°C. The LM75B's high level of precision ensures that systems are able to respond promptly to temperature variations, safeguarding them from potential damage due to overheating.

One of the standout features of the LM75B is its programmable temperature threshold and hysteresis set points, which allow for customized temperature control. This feature enables the device to be configured for a variety of applications, where specific temperature monitoring and response strategies are required.

The sensor operates with a supply voltage from 2.8V to 5.5V, making it suitable for use in both 3.3V and 5V systems. This versatility ensures that it can be easily integrated into a wide range of electronic products, from industrial controls to consumer electronics.

Furthermore, the LM75B comes in a small, surface-mountable SO8 package, which is ideal for space-constrained applications. Its small footprint does not compromise its performance or reliability, making it a top choice for designers looking for a compact temperature sensing solution.

In summary, the NXP LM75B is a high-accuracy, easy-to-use digital temperature sensor with a broad range of features that make it an excellent choice for a myriad of temperature monitoring applications. Its I2C interface, programmable set points, and compact form factor make it a versatile and indispensable component in modern electronics design.
