Products specifications

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 51 Weeks
Features series Converter, i.MX6 Voltage Regulator IC 12 Output 56-QFN-EP (8x8)
Manufacturer NXP
Series Automotive, AEC-Q100
Package Tray
Operating Temperature Range -40°C ~ 105°C (TA)
Mounting Surface Mount, Wettable Flank
Package 56-VFQFN Exposed Pad
Case / Package 56-QFN-EP (8x8)
Family Name MMPF0100
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number 568-14389, 935316087557, MMPF0100FAAZES-ND
Quantity per package 260
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 885391-MMPF0100FAAZES
Ultra Librarian 3D Model Ultra Librarian MMPF0100FAAZES CAD Model

Description

The NXP MMPF0100FAAZES is a sophisticated Power Management Integrated Circuit (PMIC) designed to meet the demanding needs of various high-performance, power-sensitive applications. This advanced PMIC is an ideal solution for delivering stable and efficient power to processors, microcontrollers, and other digital systems that require multiple power rails and high power efficiency.

Key Features:

  • Multiple Output Channels: The MMPF0100FAAZES offers a wide range of output configurations, including six buck converters and six linear regulators, providing versatility for various power requirements.
  • Programmable Output Voltage: This PMIC allows for programmable output voltages through I2C communication, enabling precise control over power delivery to meet specific application needs.
  • High-Efficiency Operation: Designed for efficiency, the PMIC features high-efficiency step-down converters that reduce power loss and improve overall system performance.
  • Integrated Power Control: With an integrated power control logic, the MMPF0100FAAZES simplifies system power sequencing and management, ensuring reliable operation.
  • Advanced Security Features: The device comes with a range of security features, including overvoltage, undervoltage, and overtemperature protection, safeguarding the system against a variety of electrical hazards.

Applications:

The NXP MMPF0100FAAZES is designed to support a broad range of applications, particularly those requiring reliable and efficient power management, such as:

  • Advanced automotive systems
  • Industrial control units
  • Networking equipment
  • Portable and wearable devices
  • Medical monitoring equipment

Technical Specifications:

  • Input Voltage Range: 2.8V to 4.5V
  • Operating Temperature: -40°C to 85°C
  • Package: 56-QFN (8x8mm)
  • Communication Interface: I2C

Overall, the NXP MMPF0100FAAZES PMIC is a highly integrated and efficient solution for complex power management challenges. Its robust feature set and flexible configurability make it an excellent choice for designers looking to optimize their power systems for performance, reliability, and efficiency.
