The NXP NX5P1100UKZ is a state-of-the-art USB power switch designed to manage power delivery and distribution in USB applications. This advanced power switch is specifically engineered to cater to the needs of modern electronics that require efficient power management solutions.

Key Features

• Current Limiting: The NX5P1100UKZ provides an adjustable current limit up to 1.5 A, ensuring protection against overcurrent conditions which could damage the USB port or the connected device.
• Over-Temperature Protection: This power switch is equipped with an over-temperature protection feature that prevents overheating by shutting down the output when the junction temperature exceeds the thermal shutdown threshold.
• Under-Voltage Lockout (UVLO): The UVLO function ensures that the device operates at safe voltage levels, protecting both the power switch and the connected devices from undervoltage conditions.
• Reverse Current Blocking: To prevent damage to the power supply, the NX5P1100UKZ includes a reverse current blocking feature that safeguards against current flowing backward through the device.

Applications

With its robust feature set, the NX5P1100UKZ is ideal for a wide range of applications, including but not limited to:

• USB Hubs
• Peripheral Ports
• Notebooks and Desktop Computers
• Portable Devices with USB Interfaces
• Docking Stations

Technical Specifications

The NX5P1100UKZ operates within a voltage range of 2.8 V to 5.5 V, making it versatile for various USB-powered devices. Its small footprint in a 6-pin package (WLCSP6) allows for seamless integration into space-constrained designs.

Quality and Reliability

NXP Semiconductors is known for its commitment to quality, and the NX5P1100UKZ is no exception. It is designed to meet the stringent requirements of the industry, ensuring a reliable performance in all supported applications.
