The NXP TJA1043TK/1Y is a high-speed Controller Area Network (CAN) transceiver that serves as an interface between a CAN protocol controller and the physical two-wire CAN bus. Designed for high-speed automotive networking, it is compliant with the ISO 11898-2:2016 standard and offers a wide range of features that ensure robust communication in the harsh automotive environment.

This transceiver is part of NXP's high-performance TJA1043 series and comes in a small leadless HVSON14 package. The TJA1043TK/1Y is designed to provide a reliable solution for data transmission rates up to 1 megabit per second (Mbps), making it suitable for a variety of applications within the vehicle, such as powertrain, chassis, safety, driver assistance, and infotainment systems.

Key Features:

• ISO 11898-2:2016 compliant for high reliability.
• Supports CAN FD for faster data communication.
• Low-power mode with remote wake-up capability for energy efficiency.
• Transmit Data (TXD) dominant time-out function to prevent bus lines from being stuck at a dominant level.
• Under-voltage detection to ensure stable operation under varying power supply conditions.
• Thermal protection to safeguard the device from overheating.
• Electrostatic discharge (ESD) protection for enhanced robustness.

The TJA1043TK/1Y is designed with a focus on fail-safe operation, featuring a Silent mode in which the transmitter is disabled, allowing for safe diagnostic or configuration mode operations. Additionally, it has an integrated differential receiver with high common-mode rejection, which provides increased immunity to electromagnetic interference (EMI) and improved signal integrity on the CAN bus.

Overall, the NXP TJA1043TK/1Y is an optimal choice for automotive and industrial applications where a robust, high-speed communication network is essential. Its advanced features ensure reliable performance and connectivity, making it a cornerstone component in modern vehicle networks.
