The ACS10S-68R-J-BULK is a 10-watt, through-hole mount, wirewound resistor manufactured by Ohmite. This resistor is designed for applications requiring high power dissipation and precise resistance values. Its robust construction and flameproof coating make it suitable for use in power supplies, motor controls, and other high-energy circuits.

Applications

• Power Supplies: Current limiting and voltage division in power supply circuits.
• Motor Controls: Providing dynamic braking and current sensing in motor control applications.
• Inrush Current Limiting: Limiting the inrush current in electronic devices.
• Load Resistors: Used as load resistors in test equipment and power circuits.
• Audio Amplifiers: Used in audio amplifiers for biasing and feedback circuits.
• Welding Equipment: Used in welding machines for current control.

Features

• Power Rating: 10 Watts.
• Resistance Value: 68 Ohms.
• Tolerance: ±5%.
• Temperature Coefficient: ±50 ppm/°C.
• Wirewound Construction: Provides high power handling capability.
• Through-Hole Mounting: Designed for easy installation on printed circuit boards (PCBs).
• Flameproof Coating: Enhances safety by preventing combustion in case of overload.

Benefits

• High Power Dissipation: Capable of handling significant power levels without overheating.
• Precise Resistance Value: Offers accurate and stable resistance for critical applications.
• Robust Construction: Durable design ensures long-term reliability.
• Safety: Flameproof coating enhances safety in high-energy circuits.
• Easy Installation: Through-hole mounting simplifies the installation process.

Additional Details

The ACS10S-68R-J-BULK wirewound resistor features a resistance value of 68 Ohms with a tolerance of ±5%. The temperature coefficient is ±50 ppm/°C, ensuring stable resistance values over a range of temperatures. The wirewound construction provides excellent power handling capability, making it suitable for applications requiring high power dissipation. The flameproof coating enhances safety by preventing combustion in case of overload. This resistor is commonly used in power supplies, motor controls, and other high-energy circuits where reliability and safety are critical.
