ON Semiconductor 2SA1700E-TL-E PNP Transistor

The ON Semiconductor 2SA1700E-TL-E is a high-quality PNP bipolar junction transistor (BJT) designed for use in a variety of applications that require low power and high efficiency. This versatile component is a fundamental building block in electronic circuits, particularly useful in amplification and switching applications.

With its compact SOT-416 package, the 2SA1700E-TL-E is optimized for space-constrained applications. The surface-mount design allows for efficient assembly in high-volume production, making it a great choice for commercial and industrial electronics. The device features a collector-emitter voltage (VCEO) of -50V and a collector current (IC) of -150mA, which makes it suitable for moderate voltage and current handling requirements.

The transistor offers a collector power dissipation (PC) of 150mW, ensuring reliable operation under typical circuit conditions. Its transition frequency (fT) is specified at 250MHz, providing good performance in high-frequency signal processing tasks. The 2SA1700E-TL-E's high gain bandwidth product allows it to be used effectively in amplifiers and oscillators where bandwidth is a critical factor.

The ON Semiconductor 2SA1700E-TL-E features a low saturation voltage, which translates to reduced power loss when the transistor is in the 'on' state. This characteristic is particularly beneficial in power management applications where energy efficiency is a priority. Additionally, the device boasts good linearity, which is essential for maintaining signal integrity in amplification applications.

With its robust construction and reliable performance, the 2SA1700E-TL-E is an excellent choice for designers looking to create energy-efficient, high-performance electronic products. Whether it's for audio amplifiers, signal processing, or power management systems, this PNP transistor from ON Semiconductor is a dependable component that can meet the demands of a wide range of electronic circuits.

Overall, the 2SA1700E-TL-E is a testament to ON Semiconductor's commitment to providing high-quality, reliable semiconductor products that enable innovation and functionality across the electronics industry.
